A Complete Guide to Claude's System Architecture

Introduction

In September 2025, Anthropic closed a $13B funding round at a $183B valuation, making it the fourth-largest private company in the world. Its flagship product, Claude Code, has attracted 115,000 active developers since its February launch, processing 195 million lines of code per week, with user growth of 300%.

Even more fascinating, Anthropic CEO Dario Amodei revealed: 90% of Claude Code's code is written by itself.

How is that possible?

How can an AI coding assistant "write itself"? What is unique about its architecture that enables it to assist — and even replace — human developers so effectively?

The answer lies in Claude's modular architecture: MCP provides tools, Skills teach how to use them, Subagents execute tasks in parallel, and Hooks ensure deterministic control — these components work together to give Claude the ability to "work like a programmer."

This article gives you a bird's-eye view of the entire architecture — the role of each component, how they work together, and quick-start configuration examples. Follow-up articles will dive deep into the details of each component.

Architecture Overview

The Claude system uses a modular architecture where components are categorized by function and work as complementary collaborators rather than hierarchical dependencies:

Key insight: These components are peer-level, complementary extensions — not hierarchical dependencies. You can freely combine them based on your needs:

Core Runtime

Agent SDK — The Runtime Engine

Agent SDK is the core runtime engine of the entire Claude Agent system, providing:

• Main Loop: The Agent's core work loop
• Context Management: Token budgets, automatic compression (triggered at 92% usage)
• Tool Dispatch: Deciding which tool to use and how to execute it
• Permission System: Controlling tool access permissions

The Agent's core operating model is a simple feedback loop:

Gather context → Execute actions → Verify work → Repeat

Built-in Tools — Core Toolset

The Claude Agent ships with 20+ core tools in three categories:

These tools are available by default with no additional configuration. Claude interacts with the computer through these tools, just like a programmer uses an IDE.

Configuration & Context

CLAUDE.md — Persistent Context

Every new conversation used to require repeating the project background, coding standards, and architectural conventions... CLAUDE.md lets you configure once, load automatically.

CLAUDE.md is like a README for AI — it tells Claude about the project's background knowledge, workflow, and conventions.

Hierarchical Override

Claude loads CLAUDE.md files in the following order, with more specific files taking higher priority:

Enterprise (lowest)
    ↓
User (~/.claude/CLAUDE.md)
    ↓
Project (./CLAUDE.md)
    ↓
Module (./src/module/CLAUDE.md) (highest)

Content Recommendations

CLAUDE.md should include the following core information:

Key principle: Keep it concise. CLAUDE.md is loaded with every conversation — making it too long wastes precious tokens.

Packaging & Distribution

Plugins — Installable Units

Team configurations are scattered, hard to share, and difficult to standardize. Everyone has their own set of Skills, Commands, Hooks... How do you unify management?

Plugins bundle Skills + Commands + Subagents + Hooks + MCP into installable units, enabling one-click distribution and team standardization.

Directory Structure

my-plugin/
├── .claude-plugin/
│   └── plugin.json     # Plugin manifest (required)
├── commands/           # Slash Commands
├── agents/             # Subagents
├── skills/             # Skills
├── hooks/              # Hooks configuration
├── .mcp.json           # MCP Server configuration
└── README.md           # Documentation

Configuration Example

// plugin.json
{
  "name": "frontend-toolkit",
  "version": "1.0.0",
  "description": "Frontend development toolkit",
  "author": "Your Team"
}

# Installation methods
claude plugin install github:your-org/your-plugin  # From GitHub
claude plugin install /path/to/plugin              # From local

Related Resources

Extension Capabilities (Complementary Modules)

The Claude system's extension capabilities consist of multiple complementary modules, each with a distinct role, working in synergy:

MCP — External Connectivity

Design Philosophy

In the traditional approach, each external data source requires custom integration, leading to an N-times-M integration nightmare. MCP provides a standardized protocol for integrate once, use everywhere.

MCP (Model Context Protocol) is designed as the USB-C port for AI applications:

Architecture Pattern

┌─────────────────┐
│   MCP Host      │  (Claude Desktop, IDE, AI Tools)
│   (Main Agent)  │
└────────┬────────┘
         │ 1:N
    ┌────┴────┬────────┬────────┐
    │ Client  │ Client │ Client │  (Protocol Clients)
    └────┬────┴────┬───┴────┬───┘
         │         │        │
    ┌────┴────┐ ┌──┴───┐ ┌─┴────┐
    │ Server  │ │Server│ │Server│  (Expose Specific Capabilities)
    │ GitHub  │ │  DB  │ │ Slack│
    └─────────┘ └──────┘ └──────┘

Use cases: Connecting to databases, integrating third-party services (GitHub, Slack, Notion), accessing private APIs, real-time data stream processing.

Configuration Example

Create .mcp.json in the project root:

{
  "mcpServers": {
    "github": {
      "command": "npx",
      "args": ["-y", "@modelcontextprotocol/server-github"],
      "env": {
        "GITHUB_TOKEN": "${GITHUB_TOKEN}"
      }
    }
  }
}

Commands — Manual Workflows

Slash Commands provide manually triggered repetitive workflows.

Example: Create .claude/commands/review.md

Please perform a code review on the current changes, focusing on:
1. Code style and consistency
2. Potential performance issues
3. Security vulnerabilities
4. Test coverage

Then type /review to trigger it.

Hooks — Deterministic Control

Hooks are the core of deterministic control — certain operations must execute and cannot rely on the LLM's judgment.

Configuration Example

Auto-format TypeScript files:

{
  "hooks": {
    "PostToolUse": [
      {
        "matcher": "Edit|Write",
        "hooks": [
          {
            "type": "command",
            "command": "jq -r '.tool_input.file_path' | { read f; [[ $f == *.ts ]] && npx prettier --write \"$f\"; }"
          }
        ]
      }
    ]
  }
}

In Practice: Autonomous Loop

Ralph Wiggum is an official Anthropic plugin that uses the Stop hook to implement an autonomous iteration loop:

/ralph-loop "Implement a TODO API with CRUD operations and tests" --max-iterations 20

How it works: The Stop hook intercepts Claude's exit, re-injects the original prompt, and continues iterating until the task is complete or the maximum iteration count is reached.

Best suited for: Tasks requiring multiple iterations (passing tests, code refactoring), and tasks with automated verification.

Subagents — Task Delegation & Parallel Execution

Design Philosophy

A single Agent faces challenges: limited context window, inability to parallelize, and unclear responsibilities. Subagents adopt the Orchestrator-Worker architecture pattern to solve these problems:

Main Agent (Orchestrator)
    ├── Analyze user request
    ├── Formulate plan
    ├── Decompose tasks
    └── Spawn specialized subagents
         ↓
    ┌────────┬────────┬────────┐
    │ Sub 1  │ Sub 2  │ Sub 3  │  (Workers - parallel execution)
    │ Code   │ Tests  │ Docs   │
    └────────┴────────┴────────┘
         ↓
    Aggregate results → Main agent synthesizes output

Core Features

Performance data: Multi-agent systems outperform single agents by 90.2%, and parallelization can cut research time by 90% (token consumption is ~15x, but worth it for complex tasks).

Configuration Example

Create a Markdown file in .claude/agents/:

---
name: Code Reviewer
description: A subagent specialized in code review
tools:
  - Read
  - Grep
  - Glob
---

You are a senior code review expert. Focus on:
1. Code quality and maintainability
2. Potential bugs and edge cases
3. Performance optimization opportunities
4. Security vulnerabilities

Skills — Procedural Knowledge

Design Philosophy

Skills are reusable playbooks for AI — modular knowledge packages that Claude can dynamically load on demand. The core design principle is Progressive Disclosure:

📚 Skills Playbook
│
├─ 📋 Table of Contents ──── [Metadata Layer] Preloaded at startup (~30-50 tokens)
│   name: "weekly-report"
│   description: "Generate standardized weekly reports"
│
├─ 📖 Main Content ────────── [Core Document Layer] Loaded when relevant (~hundreds to thousands of tokens)
│   # Weekly Report Generator
│   ## Instructions
│   Generate weekly reports following this structure...
│
└─ 📎 Appendix ────────────── [Reference Resource Layer] Loaded when needed
    references/
    ├── template.xlsx
    └── examples/

MCP vs Skills: MCP gives Claude the ability to access tools (WHAT), while Skills teach Claude how to use those tools effectively (HOW).

Core Advantages

Configuration Example

Create a directory in .claude/skills/:

my-skill/
├── SKILL.md          # Core instructions (required)
├── scripts/          # Executable scripts (optional)
└── references/       # Reference materials (optional)

SKILL.md core structure:

---
name: code-review                        # Skill name
description: Code review for quality and security    # Brief description (used for auto-matching)
---

# Code Review Skill

## Instructions
[Detailed step-by-step instructions...]

## Output Format
[Output format requirements...]

Key point: The description in the frontmatter is used for auto-matching — keep it concise and accurate.
